ER-1203 (10W max.) Splash-proof Hand Grip Type Megaphones
ER-1203
The ER-1203 is a compact splash-proof megaphone rated at 3 W output and features IPX5 water-jet-resistant designs.
| Power Source | R6P (AA) × 4 (6 V DC) |
|---|---|
| Rated Output | 3 W |
| Maximum Output | 4 W |
| Battery Life | Approx. 8 hours (JEITA)* |
| Audible Range | Approx. 125 m (JEITA)* |
| Frequency Response | 500 - 6,000 Hz (SPL -20 dB) |
| Magnetic Circuit | Neodymium magnet, inner magnet type |
| Diaphragm | Polyimide film (voice coil, bobbin) |
| Anti-bacteria Treatment | Mouth and handle |
| Water Protection | IPX5 |
| Operating Temperature | -10℃ to +40℃ |
| Finish | Horn: ASA resin, clear dark gray Other: ASA resin, dark gray Strap: Nylon, black |
| Dimensions | 137 (W) × 257.8 (H) × 210 (D) mm |
| Weight | 610 g (without batteries) |
| Option | Wall mounting bracket for megaphone: SP-1100 |
- Note: Batteries are optional.
- * JEITA: Japan electronics and information technology industries association. (EIAJ TT-4501A)
